其中：compatible = “mediatek,cap_touch” 必须对应

gt9xx_driver.c中的：

static const struct of_device_id gt9xx_dt_match[] = { {.compatible = "mediatek,cap_touch"}, {},};

一般修改以下几个：

reg = <0x5D> 指的是TP I2C设备地址（7位） 我们用的是0x5D

interrupts = <46 IRQ_TYPE_EDGE_FALLING> 指的是中断号46（GPIOtable里能看到），下降沿触发

int-gpio = <&pio 35 0>; 中断脚 GPIO35（根据硬件接法修改）

rst-gpio = <&pio 45 0>; 复位脚GPIO45（根据硬件接法修改）

&touch {
        vtouch-supply = <&mt6323_vgp2_reg>;
        tpd-resolution = <768 1024>;
        use-tpd-button = <0>;
        tpd-key-num = <4>;
        tpd-key-local= <139 172 158 0>;
        tpd-key-dim-local = <60 850 50 30 180 850 50 30 300 850 50 30 420 850 50 30>;
        tpd-max-touch-num = <5>;
        tpd-filter-enable = <1>;
        tpd-filter-pixel-density = <124>;
        tpd-filter-custom-prameters = <0 0 0 0 0 0 0 0 0 0 0 0>;
        tpd-filter-custom-speed = <0 0 0>;
        pinctrl-names = "default", "state_eint_as_int", "state_eint_output0", "state_eint_output1",
                "state_rst_output0", "state_rst_output1";
        pinctrl-0 = <&CTP_pins_default>;
        pinctrl-1 = <&CTP_pins_eint_as_int>;
        pinctrl-2 = <&CTP_pins_eint_output0>;
        pinctrl-3 = <&CTP_pins_eint_output1>;
        pinctrl-4 = <&CTP_pins_rst_output0>;
        pinctrl-5 = <&CTP_pins_rst_output1>;
        status = "okay";
};
