Introduction
Customized Player-This article interpret how to implement a customized video player instead of the UI of android’s MediaController and how to handle error of android’s MediaPlayer to enable it continue replaying from the last position after reset the engine of media player

Background
I have googled lots of open source player for android, unfortunately almost all of the players are just for music but not for video, audio isn’t easy to play failed compared with video, I implement the customized player to enable developer easy to modify controller UI of media player and pay attention to the drawback of VideoView control provided by Android
Using the code
Android provide MediaPlayer and VideoView/MediaController to create player, but if dislike the UI and hope to redesign a player to enable it increasing more features such as adjusting volume or full screen , you can refer to my customized player code , it include 3 files, MediaControllerEx.java, VideoViewEx.java, PlayerActivity.java, MediaControllerEx.java implement the controller UI layout for player,if you want to adjust the SeekBar height, you should replace the default style with your customized style.
// layout your own UI for controller
protected View makeControllerView() {
LayoutInflater inflate = (LayoutInflater) mContext
.getSystemService(Context.LAYOUT_INFLATER_SERVICE);
mRoot = inflate.inflate(R.layout.media_controller_view, null);
initControllerView(mRoot);

return mRoot;
}
//SeekBar style for controller
<style>
<item>false</item>
<item>@drawable/seekbar_style_drawable</item>
<item>@drawable/seekbar_style_drawable</item>
<item>10dip</item>
<item>10dip</item>
<item>@drawable/controller_playhead_drawable</item>
<item>8px</item>
<item>true</item>
</style>

//assign the seek position when setting video path in VideoViewEx.java
public void setVideoPath(String path,int position) {
setVideoURI(Uri.parse(path),position);
}
/**
* The MediaPlayer often change to error state when playing video,and then prompt "can't play this video" dialog, so you have to handle these error via remembering the played time and replaying video after reset MediaPlayer engine
*/
private MediaPlayer.OnErrorListener mOnErrorListener = new MediaPlayer.OnErrorListener() {
public boolean onError(MediaPlayer mp, int what, int extra) {
switch (what) {
case MediaPlayer.MEDIA_ERROR_SERVER_DIED:
Toast.makeText(PlayerActivity.this, "MEDIA_ERROR_SERVER_DIED",
Toast.LENGTH_SHORT).show();
![]()
showErrorDlg(what);
return true;
case MediaPlayer.MEDIA_ERROR_NOT_VALID_FOR_PROGRESSIVE_PLAYBACK:
Toast.makeText(PlayerActivity.this,
"MEDIA_ERROR_NOT_VALID_FOR_PROGRESSIVE_PLAYBACK",
Toast.LENGTH_SHORT).show();
break;
case MediaPlayer.MEDIA_ERROR_UNKNOWN:
Toast.makeText(PlayerActivity.this, "MEDIA_ERROR_UNKNOWN",
Toast.LENGTH_SHORT).show();
break;
}
setProgressContainer(true, getString(R.string.msg_handle_error));

int position=mVideoView.getCurrentPosition();
if(position>0){
mCurPosition=position;
}
mVideoView.setVideoPath(mCurrentMediaUrl,position);
return true;
}
};
Points of Interest
My interest includes streaming player, decoder/encoder/demuxer of android's openCore media framework
History
CustomizedPlayer 0.1 version.
备注:懒得用英文再描述一遍rockplayer2如何使用rockplayer2如何使用,需要再次建立的地方是怎样在播放过程中有相应的提醒信息(如正在缓冲,网络断线,出错处理等)
