near top

SouthOutside：Outside bottom

EastOutside：Outsideright

WestOutside：Outside left

NorthEastOutside：Outside top right

NorthWestOutside：Outside top left

SouthEastOutside：Outside bottom right

SouthWestOutside：Outside bottom left

Best：Least conflict with data in plot

BestOutside：Least unused space outside plot

通常，用'Best‘比较不错

高级用法2：指定显示某几条曲线的legend：

方法1：复杂到吐血

例如你有25条曲线，想显示其中1，6，11，16，21的legend，则

for i = [2:5 7:10 12:15 17:20 22:25]

set(get(get(H(i),'Annotation'),'LegendInformation'),'IconDisplayStyle','off');

end

legend('1','6','11','16','21');

方法2：简单到郁闷

H = plot(data);

legend(H([1 6 11 16 21],'1,'6','11’,'16','21');

高级用法3：legend横排

hl = legend(H([1 6 11 16 21],'1,'6','11’,'16','21');

set(hl,'Orientation','horizon')

高级用法4：不显示方框：

hl = legend(H([1 6 11 16 21],'1,'6','11’,'16','21');

set(hl,'Box','off');

参考文献

doc legend

Site：

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

另外，去掉legend边框，可以参考：

legend('x','y')

legend('boxoff')

写两次就好了。matlablegendmatlablegend我最初尝试着写成legend('x','y','boxoff')是不行的。

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

修改legend的字体：

legend1=legend('x','y');

set(legend1,'FontName','Times NewRoman','FontSize',12,'FontWeight','normal');

修改legend位置：

i=0;%i=0，自动调整最佳位置；i=1，右上；i=2，左上；i=3，左下；i=4，右下；

legend1=legend('x','y'，i);

20160518

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

最好的说明文档，当然是帮助文档：

matlab:

doc legend

legend('hide'), legend(axes_handle,'hide') makes the legend in thecurrent axes or the axes specified by axes_handle invisible.
