(建议读者在看本章之前,先看how tomcat works 读书笔记(一)----------一个简单的web服务器 )

回顾我们上一章,我们开发了一个最最简单的web服务器,它可以使用户访问服务器内的静态资源。当然这是远远不够的,在这一节里,我们就试着让服务器在能相应静态资源的基础上继续支持servlet。

servlet接口

javax.servlet.Servlet接口定义了五个方法,如下:

我们所使用的servlet都是Servlet接口的间接实现类。

每当我们实例化一个servlet的时候,servlet容器都会先唯一的调用一次init()方法进行初始化,然后再调用service()方法来处理用户的需求,最后在销毁servlet前容器会调用destroy()方法。

我们看看,这一节我们要用的测试servlet。how tomcat works

import javax.servlet.*;
import com.jspsmart.upload.Request;


import java.io.IOException;
import java.io.PrintWriter;


public class PrimitiveServlet implements Servlet {


  public void init(ServletConfig config) throws ServletException {
    System.out.println("init");
  }


  public void service(ServletRequest request, ServletResponse response)
    throws ServletException, IOException {
    System.out.println("from service");
    PrintWriter out = response.getWriter();
    out.println("Hello. Roses are red.");
    out.print("Violets are blue.");
 //   out.flush();
  }


  public void destroy() {
    System.out.println("destroy");
  }


  public String getServletInfo() {
    return null;
  }
  public ServletConfig getServletConfig() {
    return null;
  }


}

Servlet定义的5个方法,它都实现了(不过我们这一节要实现的servlet还没有能力自动调用init和destroy方法)。

再看看我们的主方法,程序就从这里开始(和上一节的HttpServer差别不是很大)

package ex02.pyrmont;


import java.net.Socket;
import java.net.ServerSocket;
import java.net.InetAddress;
import java.io.InputStream;
import java.io.OutputStream;
import java.io.IOException;


public class HttpServer1 {


  /** WEB_ROOT is the directory where our HTML and other files reside.
   *  For this package, WEB_ROOT is the "webroot" directory under the working
   *  directory.
   *  The working directory is the location in the file system
   *  from where the java command was invoked.
   */
  // shutdown command
  private static final String SHUTDOWN_COMMAND = "/SHUTDOWN";


  // the shutdown command received
  private boolean shutdown = false;


  public static void main(String[] args) {
    HttpServer1 server = new HttpServer1();
    server.await();
  }


  public void await() {
    ServerSocket serverSocket = null;
    int port = 8080;
    try {
      serverSocket =  new ServerSocket(port, 1, InetAddress.getByName("127.0.0.1"));
    }
    catch (IOException e) {
      e.printStackTrace();
      System.exit(1);
    }


    // Loop waiting for a request
    while (!shutdown) {
      Socket socket = null;
      InputStream input = null;
      OutputStream output = null;
      try {
        socket = serverSocket.accept();
        input = socket.getInputStream();
        output = socket.getOutputStream();


        // create Request object and parse
        Request request = new Request(input);
        request.parse();


        // create Response object
        Response response = new Response(output);
        response.setRequest(request);  //没有再这里直接处理静态资源
	                               //而是判断到底请求的事静态资源还是servlet


        // check if this is a request for a servlet or a static resource
        // a request for a servlet begins with "/servlet/"
        if (request.getUri().startsWith("/servlet/")) {
          ServletProcessor1 processor = new ServletProcessor1();
          processor.process(request, response);
        }
        else {
          StaticResourceProcessor processor = new StaticResourceProcessor();
          processor.process(request, response);
        }


        // Close the socket
        socket.close();
        //check if the previous URI is a shutdown command
        shutdown = request.getUri().equals(SHUTDOWN_COMMAND);
      }
      catch (Exception e) {
        e.printStackTrace();
        System.exit(1);
      }
    }
  }
}

大家可以很清楚地看到,这部分和上一节的不同主要就在response部分,更准确的说就是在这

if (request.getUri().startsWith("/servlet/")) {
          ServletProcessor1 processor = new ServletProcessor1();
          processor.process(request, response);
        }
        else {
          StaticResourceProcessor processor = new StaticResourceProcessor();
          processor.process(request, response);
        }

我们看看,如果请求是以servlet开头的该如何处理。

package ex02.pyrmont;


import java.net.URL;
import java.net.URLClassLoader;
import java.net.URLStreamHandler;
import java.io.File;
import java.io.IOException;
import javax.servlet.Servlet;
import javax.servlet.ServletRequest;
import javax.servlet.ServletResponse;


public class ServletProcessor1 {


  public void process(Request request, Response response) {


    String uri = request.getUri();
    String servletName = uri.substring(uri.lastIndexOf("/") + 1);

    URLClassLoader loader = null;


    try {
      // create a URLClassLoader   //try部分的主要功能就是产生一个URLClassLoader
      URL[] urls = new URL[1];
      URLStreamHandler streamHandler = null;

      File classPath = new File(Constants.WEB_ROOT);
      //下面的URL构造函数为
      //java.net.URL.URL(String protocol, String host, String file) throws MalformedURLException
      String repository = (new URL("file", null, classPath.getCanonicalPath() + File.separator)).toString() ;



      System.out.println(servletName+"*****"+Constants.WEB_ROOT+"   "+repository);
      //下面的URL构造函数为
      //java.net.URL.URL(URL context, String spec, URLStreamHandler handler) throws MalformedURLException
      //至于 URLStreamHandler是什么东西 暂时不必理会
      urls[0] = new URL(null, repository, streamHandler);
      loader = new URLClassLoader(urls);
    }
    catch (IOException e) {
      System.out.println(e.toString() );
    }
    Class myClass = null;
    try {
      myClass = loader.loadClass(servletName);   //加载请求的servlet

    }
    catch (ClassNotFoundException e) {
      System.out.println(e.toString());
    }


    Servlet servlet = null;


    try {
      servlet = (Servlet) myClass.newInstance();  //生成实例 并调用service方法
      servlet.service((ServletRequest) request, (ServletResponse) response);
    }
    catch (Exception e) {
      System.out.println(e.toString());
    }
    catch (Throwable e) {
      System.out.println(e.toString());
    }


  }


}

看看另一部分,如果请求的不是servlet(这一节就是静态资源)该如何处理

package ex02.pyrmont;


import java.io.IOException;


public class StaticResourceProcessor {


  public void process(Request request, Response response) {
    try {
      response.sendStaticResource();
    }
    catch (IOException e) {
      e.printStackTrace();
    }
  }
}

跟第一节没有什么区别。

我们的request类要实现ServletRequest接口

package ex02.pyrmont;


import java.io.InputStream;
import java.io.IOException;
import java.io.BufferedReader;
import java.io.UnsupportedEncodingException;
import java.util.Enumeration;
import java.util.Locale;
import java.util.Map;


import javax.servlet.AsyncContext;
import javax.servlet.DispatcherType;
import javax.servlet.RequestDispatcher;
import javax.servlet.ServletContext;
import javax.servlet.ServletInputStream;
import javax.servlet.ServletRequest;
import javax.servlet.ServletResponse;




public class Request implements ServletRequest {


  private InputStream input;
  private String uri;


  public Request(InputStream input) {
    this.input = input;
  }


  public String getUri() {
    return uri;
  }


  private String parseUri(String requestString) {
    int index1, index2;
    index1 = requestString.indexOf(' ');
    if (index1 != -1) {
      index2 = requestString.indexOf(' ', index1 + 1);
      if (index2 > index1)
        return requestString.substring(index1 + 1, index2);
    }
    return null;
  }


  public void parse() {
    // Read a set of characters from the socket
    StringBuffer request = new StringBuffer(2048);
    int i;
    byte[] buffer = new byte[2048];
    try {
      i = input.read(buffer);
    }
    catch (IOException e) {
      e.printStackTrace();
      i = -1;
    }
    for (int j=0; j

同样的response也要实现ServletResponse接口
package ex02.pyrmont;


import java.io.OutputStream;
import java.io.IOException;
import java.io.FileInputStream;
import java.io.FileNotFoundException;
import java.io.File;
import java.io.PrintWriter;
import java.util.Locale;
import javax.servlet.ServletResponse;
import javax.servlet.ServletOutputStream;


import com.sun.org.apache.bcel.internal.generic.NEW;


public class Response implements ServletResponse {


  private static final int BUFFER_SIZE = 1024;
  Request request;
  OutputStream output;
  PrintWriter writer;


  public Response(OutputStream output) {
    this.output = output;
  }


  public void setRequest(Request request) {
    this.request = request;
  }


  /* This method is used to serve a static page */
  public void sendStaticResource() throws IOException {
    byte[] bytes = new byte[BUFFER_SIZE];
    FileInputStream fis = null;
    try {
      /* request.getUri has been replaced by request.getRequestURI */
    	System.out.println(Constants.WEB_ROOT+" ***** "+ request.getUri());
      File file = new File(Constants.WEB_ROOT, request.getUri());
      fis = new FileInputStream(file);
      /*
         HTTP Response = Status-Line
           *(( general-header | response-header | entity-header ) CRLF)
           CRLF
           [ message-body ]
         Status-Line = HTTP-Version SP Status-Code SP Reason-Phrase CRLF
      */
      int ch = fis.read(bytes, 0, BUFFER_SIZE);
      System.out.println("response  **");
      while (ch!=-1) {
        output.write(bytes, 0, ch);
        ch = fis.read(bytes, 0, BUFFER_SIZE);
      }
    }
    catch (FileNotFoundException e) {
      String errorMessage = "HTTP/1.1 404 File Not Found\r\n" +
        "Content-Type: text/html\r\n" +
        "Content-Length: 23\r\n" +
        "\r\n" +
        "
File Not Found
";
      output.write(errorMessage.getBytes());
    }
    finally {
      if (fis!=null)
        fis.close();
    }
  }


  public PrintWriter getWriter() throws IOException {
    // autoflush is true, println() will flush,
    // but print() will not.
    writer = new PrintWriter(output, true);
    return writer;
  }
  //一样 部分代码 直接让Eclipse 自动生成即可


}

试验一下
:8080/servlet/PrimitiveServlet


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"brush:java;">  public void service(ServletRequest request, ServletResponse response)throws ServletException, IOException {System.out.println("from service");Request r=(Request) request;System.out.println(r.parseUri("sdf"));PrintWriter out = response.getWriter();out.println("Hello. Roses are red.");out.print("Violets are blue.");out.flush();  }
我把servlet类中的service改成上面的样子,大家看看,其实request的parseUri方法在servlet里是不应该被使用的!
那怎么办?
第一种,将parseUri方法的public方法改成默认的访问修饰符,包外的类就不能访问了。
不过还有另一种方式
门面模式!!
在上面的例子中,我们写的request实现了ServletRequest,我们可以再写一个类RequestFacade类让他也实现ServletRequest(response 类似)

package ex02.pyrmont;


import java.io.IOException;
import java.io.BufferedReader;
import java.io.UnsupportedEncodingException;
import java.util.Enumeration;
import java.util.Locale;
import java.util.Map;
import javax.servlet.RequestDispatcher;
import javax.servlet.ServletInputStream;
import javax.servlet.ServletRequest;


public class RequestFacade implements ServletRequest {


  private ServletRequest request = null;


  public RequestFacade(Request request) {
    this.request = request;
  }


    public String getRemoteHost() {
    return request.getRemoteHost();
  }


  //省略对ServletRequest接口的实现
  //servletrequest接口的方法 在RequestFacade 内部实现时 都调用类的属性request来实现


  public void setCharacterEncoding(String encoding)
    throws UnsupportedEncodingException {
    request.setCharacterEncoding(encoding);
  }


}
再看看  ServletProcessor 改成如下


    Servlet servlet = null;
    RequestFacade requestFacade = new RequestFacade(request);
    ResponseFacade responseFacade = new ResponseFacade(response);
    try {
      servlet = (Servlet) myClass.newInstance();
      servlet.service((ServletRequest) requestFacade, (ServletResponse) responseFacade);
    }
    catch (Exception e) {
      System.out.println(e.toString());
    }
    catch (Throwable e) {
      System.out.println(e.toString());
    }
httpServer 也改成如下
 if (request.getUri().startsWith("/servlet/")) {
          ServletProcessor2 processor = new ServletProcessor2();
          processor.process(request, response);
        }

app1给servlet里面传递的参数实际上是Request类型的,有调用parseUri方法的危险。how tomcat works
app2给servlet里面传递的参数实际上是RequestFacade,它根本就没有parseUri方法,自然就安全了。
这篇文章中 对书中的源码有删减 大家可以下载完整版本的
深入剖析tomcat 源码
