Java利用VLC开发简易视屏播放器(2)

播放器窗体类：

package deng.test;
import java.awt.BorderLayout;
import java.awt.event.ActionEvent;
import java.awt.event.ActionListener;
import java.awt.event.MouseAdapter;
import java.awt.event.MouseEvent;
import javax.swing.JButton;
import javax.swing.JFrame;
import javax.swing.JMenu;
import javax.swing.JMenuBar;
import javax.swing.JMenuItem;
import javax.swing.JPanel;
import javax.swing.JProgressBar;
import javax.swing.JSlider;
import javax.swing.border.EmptyBorder;
import javax.swing.event.ChangeEvent;
import javax.swing.event.ChangeListener;

import uk.co.caprica.vlcj.component.EmbeddedMediaPlayerComponent;
import uk.co.caprica.vlcj.player.embedded.EmbeddedMediaPlayer;

@SuppressWarnings("serial")
public class Window extends JFrame{

    private JPanel contentPane; //顶层容器，整个播放页面的容器
    private JMenuBar menuBar;   //菜单栏
    private JMenu mnFile,mnSetting,mnHelp;  //文件菜单
    private JMenuItem mnOpenVideo,mnExit;   //文件菜单子目录，打开视屏、退出
    private JPanel panel;   //控制区域容器
    private JProgressBar progress;  //进度条
    private JPanel progressPanel;   //进度条容器
    private JPanel controlPanel;    //控制按钮容器
    private JButton btnStop,btnPlay,btnPause;   //控制按钮，停止、播放、暂停
    private JSlider slider;     //声音控制块


    EmbeddedMediaPlayerComponent playerComponent;   //媒体播放器组件

    public static void main(String[] args) {

    }

    //MainWindow构造方法，创建视屏播放的主界面
    public Window(){
        setTitle("   小婷婷专属播放器   Copyright@dengchaoqun");
        setDefaultCloseOperation(JFrame.EXIT_ON_CLOSE);
        setBounds(200,80,900,600);
        contentPane=new JPanel();
        contentPane.setBorder(new EmptyBorder(5, 5, 5, 5));
        contentPane.setLayout(new BorderLayout(0,0));
        setContentPane(contentPane);

        /*视频播放窗口中的菜单栏*/
        menuBar=new JMenuBar();
        setJMenuBar(menuBar);

        mnFile=new JMenu("文件");     //设置菜单名
        menuBar.add(mnFile);
        mnSetting=new JMenu("设置");
        menuBar.add(mnSetting);
        mnHelp=new JMenu("帮助");
        menuBar.add(mnHelp);

        mnOpenVideo =new JMenuItem("打开文件"); //设置文件菜单子目录打开文件
        mnFile.add(mnOpenVideo);

        mnExit =new JMenuItem("退出");    //设置文件菜单子目录退出
        mnFile.add(mnExit);

        //打开文件
        mnOpenVideo.addActionListener(new ActionListener() {

            @Override
            public void actionPerformed(ActionEvent e) {
                // TODO Auto-generated method stub
                PlayerMain.openVideo();
            }
        });

        //退出
        mnExit.addActionListener(new ActionListener() {

            @Override
            public void actionPerformed(ActionEvent e) {
                // TODO Auto-generated method stub
                PlayerMain.exit();
            }
        });


        /*视屏窗口中播放界面部分*/
        JPanel videoPane=new JPanel();
        contentPane.add(videoPane, BorderLayout.CENTER);
        videoPane.setLayout(new BorderLayout(0,0));

        playerComponent=new EmbeddedMediaPlayerComponent();
        videoPane.add(playerComponent);

        /*视屏窗口中控制部分*/

        panel=new JPanel();     //实例化控制区域容器
        videoPane.add(panel,BorderLayout.SOUTH);

        progressPanel=new JPanel(); //实例化进度条容器
        panel.add(progressPanel, BorderLayout.NORTH);

        //添加进度条
        progress=new JProgressBar();
        progressPanel.add(progress);
        //panel.add(progress,BorderLayout.NORTH);
        progress.addMouseListener(new MouseAdapter() {
            @Override
            public void mouseClicked(MouseEvent e){     //点击进度条调整视屏播放进度
                int x=e.getX();
                PlayerMain.jumpTo((float)x/progress.getWidth());
            }
        });
        progress.setStringPainted(true);


        controlPanel=new JPanel();      //实例化控制按钮容器
        panel.add(controlPanel,BorderLayout.SOUTH);

        //添加停止按钮
        btnStop=new JButton("停止");
        btnStop.addMouseListener(new MouseAdapter() {
            @Override
            public void mouseClicked(MouseEvent e) {
                // TODO Auto-generated method stub
                PlayerMain.stop();
            }
        });
        controlPanel.add(btnStop);

        //添加播放按钮
        btnPlay=new JButton("播放");
        btnPlay.addMouseListener(new MouseAdapter() {
            @Override
            public void mouseClicked(MouseEvent e) {
                // TODO Auto-generated method stub
                PlayerMain.play();
            }
        });
        controlPanel.add(btnPlay);

        //添加暂停按钮
        btnPause=new JButton("暂停");
        btnPause.addMouseListener(new MouseAdapter() {
            @Override
            public void mouseClicked(MouseEvent e) {
                // TODO Auto-generated method stub
                //PlayerMain.dispose();
                PlayerMain.pause();
            }
        });
        controlPanel.add(btnPause);

        //添加声音控制块
        slider=new JSlider();
        slider.setValue(80);
        slider.setMaximum(100);
        slider.addChangeListener(new ChangeListener() {

            @Override
            public void stateChanged(ChangeEvent e) {
                // TODO Auto-generated method stub
                PlayerMain.setVol(slider.getValue());
            }
        });
        controlPanel.add(slider);
    }

    //获取播放媒体实例（某个视频）
    public EmbeddedMediaPlayer getMediaPlayer() {
        return playerComponent.getMediaPlayer();
    }

    //获取进度条实例
    public JProgressBar getProgressBar() {
        return progress;
    }

}

效果如下：

（6）在视频播放面板上操作视频接口方法：

playerComponent = new EmbeddedMediaPlayerComponent();
        panel.add(playerComponent);
        //视频表面的鼠标事件
        playerComponent.getVideoSurface().addMouseListener(new MouseListener() {

            @Override
            public void mouseReleased(MouseEvent e) {
                // TODO Auto-generated method stub

            }

            @Override
            public void mousePressed(MouseEvent e) {
                // TODO Auto-generated method stub

            }

            @Override
            public void mouseExited(MouseEvent e) {
                // TODO Auto-generated method stub

            }

            @Override
            public void mouseEntered(MouseEvent e) {
                // TODO Auto-generated method stub

            }

            @Override
            public void mouseClicked(MouseEvent e) {
                // TODO Auto-generated method stub
                System.out.println("**************");
            }
        });

（7）项目总结：应用了开源vlc，运用了jna技术，实现了多媒体视频播放。
